Portable LED Screen Chemotherapy Medical Syringe Infusion Pump for Hospital
Portable LED Screen Chemotherapy Medical Syringe Infusion Pump for Hospital
Portable LED screen chemotherapy medical syringe infusion pump for hospital: An infusion pump is usually a mechanical or electronic control device that acts on an infusion catheter to control the rate of infusion. It is often used in situations where the volume and dosage of fluids need to be strictly controlled, such as during the use of pressors, antiarrhythmic drugs, intravenous fluids in infants, or intravenous anesthesia. The following combined with clinical practical application to talk about the daily operation, maintenance and preservation of infusion pump should pay attention to the problem.
Send Inquiry
Product Description
1. Product Introduction of Portable LED screen chemotherapy medical syringe infusion pump for hospital
Portable LED screen chemotherapy medical syringe infusion pump for hospital: The product is a volumetric infusion pump, features in high safety, easy operation and long life. Flow control with high accuracy and comprehensive alarm measures ensure patient's safety and optimum therapeutic effect.
2. Product Parameter (Specification) of Portable LED screen chemotherapy medical syringe infusion pump for hospital
| Infusion modes |
4 infusion modes: 1, Flow-rate: ml/h; 2, Time-amount: ml/h; 3, Drop-rate: d/min; 4, Body-weight: mg/kg/h |
| Parameter range |
1, Flow-rate: 1.0~1200.0 ml/h, 0.1ml/h step; 2, Time: 1s~99h59m59s, 1s step; 3, Drop-rate: 1~333 d/min, 1 d/min step; 4, Dose: 0.1~999.9 mg, 0.1mg step; 5, mg/kg/h: 0.001~999.999 mg/kg/h, 0.001 mg/kg/h step; 6, Body-weight: 1~300 kg, 1kg step; 7, KVO rate: 1.0~5.0 ml/h, 0.1 ml/h step; 8, Bolus rate: 50.0~800.0 ml/h, 0.1 ml/h step; 9, Bolus volume: 0.1~99.9 ml/h, 0.1ml step |
| Precision | Better than ±5% (using a calibrated or a special IV-set) |
| Alarm |
1, Air in tube, 5 grades of sensitivity (double bubble alarm); 2, Bubble sensor fault; 3.1, Upper-end occlusion, -20~ -60 kPa,8 grades of sensitivity; 3.2, Upper-end base-pressure fault; 4.1, Lower-end occlusion, 20~ 140 kPa,8 grades of sensitivity; 4.2, Lower-end base-pressure fault; 5.1, Pump rotation fault; 5.2, Inverse-infusion; 6, Abnormal door-opening; 7, Low battery power, battery fault; 8, Overtime pause; 9, Completed infusion; 10, AC power fault; 11, MCU fault, and stop infusion; 12, Battery temperature is too high. |
| Data function |
1, Memory of calibration: Records the calibration data of tube automatically for application; 2, Memory of parameter: Records the latest infusion parameter for next operation; 3, Historical records: records latest 1000 infusion events. (what/when/why,flow-rate, etc.) |
| Safety classification | Class I; Internal power supply, CF type, IPX4 equipment |
| Power supply | AC 100~240V, 50/60Hz, Built-in rechargeable Li-battery |
| Power consumption:20VA | |
| Working time of battery: 7h@25ml/h | |
| Weight and size | 130mm(w)*206mm(h)*118mm(t); about 1.6kg |
| Optional accessories |
1, Warmer; 2, Wireless communicating module. |
3. Product Feature And Application of Portable LED screen chemotherapy medical syringe infusion pump for hospital
Portable LED screen chemotherapy medical syringe infusion pump for hospital: Reliable and Safe:
1. Additional set of bubble alarm design(double bubble alarm) ensure more secure infusion;
2. Advanced safety design able to stop infusion and alarm even if the CPU damage,the medical staff can ues it safely;
multipurpose:
It can be transfused, transfused blood and transported nutrient solution.
4. Product Details of Portable LED screen chemotherapy medical syringe infusion pump for hospital
5. Product Certification of Portable LED screen chemotherapy medical syringe infusion pump for hospital
Company Certification
Company Profile
Company Exhibition
6. Deliver,Shipping And Serving Of Portable LED screen chemotherapy medical syringe infusion pump for hospital
| Shipping Method | Shipping Terms | Area |
| Express | TNT /FEDEX /DHL/ UPS | All Countries |
| Sea | FOB/ CIF /CFR /DDU | All Countries |
| Railway | DDP/TT | Europe Countries |
| Ocean +Express | DDP/TT | Europe Countries /USA/Canada/Australia /Southeast Asia /Middle East |
7. FAQ of Portable LED screen chemotherapy medical syringe infusion pump for hospital
Q:Are you a trading company or a manufacturer?
R:We are a professional manfacturer and we have export service company.
R:Yes! We can send some samples. You pay the sample cost and freight.We return the sample cost after bluk order.
R:MOQ is 1000pcs.
R:Yes! We accept the trial order.
R:We accept Alipay,TT with 30% deposit.L/C at sight, Western Union.
R:Usually 20-45days.
R:Yes, Logo printing as customer's design sticker, hangtag ,boxes,carton making.
R:Yes! We can be our distributor when you order is over $30000.00.
R:Yes! The sales target finished amount is $500000.00.
R:Yes! We have!
R:CE, FDA and ISO.
R:Yes, we also can camera with you when you need.
R:Yes! We can do that.
R:Yes!
R:Yes, pls supply the destination to us.We will check the shipping cost to you.
R:After order is confirmed, we have a meeting with the all dept. before production, investigate all the workmanship and technical details, make sure all the details are under control.
R:Our nearest port is Xiamen,Fujian, China.
